Picosecond Lasers for TCSPC

Becker & Hickl diode lasers deliver picosecond light pulses at high repetition rates. Thus, they are perfect with advanced TCSPC techniques. The lasers can also have a CW mode to generate a continuous high-power beam of light.

Both in the picosecond pulsed mode and in the CW mode the output power is stabilized by internal power regulator loops. The lasers feature low intensity noise and high power stability.

The lasers have integrated beam profile correction optics. They deliver beams approximating circular cross-sections with low astigmatism. Lasers can be free space coupled, or fiber coupled.

Output power of the lasers can be controlled by external signals, and have fast reacting on/off control input. The input can be used to control multiple lasers. Synchronization inputs allow the lasers pulse train to be synchronized with these other lasers.

The drive electronics are integrated into the laser head. Thus, all that is needed is 12 volts DC. Laser safety include a connection box with key switch and emission indicator.

These high-performance lasers are fully compatible with the Becker & Hickl SPC or Simple Tau TCSPC devices. They also form an essential element of the DCS-120 confocal scanning systems, as well as the FLIM systems for a wide range of other laser scanning microscopes.

Please see our brochure for further information on the available lasers for your TCSPC applications.

• Available wavelengths:  375 nm, 405 nm, 445 nm, 473 nm, 488 nm, 515 nm, 640 nm, 685 nm, 785 nm, 1064 nm
• 60% coupling efficiency into single-mode fiber
• TEM00 mode
• Pulse width down to 40 ps
• Pulsed and CW operation
• Beam-profile correction optics
• Free-beam output or single-mode fibre coupling
• Repetition rate 20-50-80 MHz
• Low skew trigger output
• Extremely low RF noise
• Cooled laser diode
• Fast on / off / multiplexing capability
• Synchronisation input
• Complete electronics integrated in laser housing

• Available wavelengths: 375 nm, 405 nm, 445 nm, 473 nm, 488 nm, 515 nm, 640 nm, 685 nm, 785 nm, 1064 nm
• 40 mm x 40 mm x 110 mm
• Free-beam or fibre output
• Pulse width down to 60 ps
• Repetition rate 20 MHz / 50 MHz / cw ( switchable)
• All electronics integrated
• No external driver unit
• Simple +12V supply

• Available wavelengths: 532 nm, 561 nm, 594 nm
• 40 mm x 40 mm x 140 mm
• Free-beam or fibre output
• Pulse width down to 50 ps
• Repetition rate 20 MHz / 50 MHz ( switchable )
• CW-equivalent power 0.3 to 0.5 mW
• All electronics integrated
• No external driver unit
• Simple +12V supply

• Available wavelengths: 405 nm, 450 nm, 525 nm, 640 nm, 685 nm, 785 nm, 915 nm
• 40 mm x 40 mm x 110 mm
• Free-beam or fiber output
• Pulse width down to 60 ps
• Repetition rate 20 MHz / 50 MHz
• Optical power up to 40 mW
• All electronics integrated
• No external driver unit
• Simple +12V supply
